Description

With a wide frequency response of 40 Hz – 18 kHz and the ability to handle SPLs in excess of 144 dB, the D4 dynamic instrument microphone is an excellent choice for miking instruments requiring precise, low frequency reproduction such as large rack toms, floor toms, cajon, djembe, tympani, leslie bottom, bass flute, saxophone and baritone saxophone, trombone, acoustic bass, bass cabinets and small kick drums.

The D4 is lightweight, compact and easy to position. Used for stage, studio and broadcast applications, the D4 dynamic instrument microphone is designed with a Hypercardioid pickup pattern for isolation and feedback control. The D4 Hypercardioid is also equipped with a VLM™ diaphragm for natural accurate sound reproduction.

What’s in the Box?

1 x D4 Instrument Microphone

1 x DCLIP Microphone Clip

1 x P1 Carrying Pouch

General

Transducer Type: Dynamic

Frequency Response: 40 Hz – 18 kHz

Polar Pattern: Hypercardioid

Output Impedance: 280 ohms

Sensitivity: 1.4 mV / Pa @ 1k

Capsule Technology: VLM Type D

Off Axis Rejection: >20 dB

Maximum SPL: ≥144 dB

Power Requirements: None

Connector: 3-pin XLRm

Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector

Physical & Dimensions

Materials: Finish Black Hard Coat

Weight: 128 g / 4.5 oz

Length: 100 mm / 3.9 in
