Description

Compact converter for HDMI to 12G-SDI including power supply unit

• For connecting HDMI cameras and computers to professional SDI equipment
• Two 12G-SDI outputs that can be set to Level A or Level B 3G-SDI signal formats
• Equipped with full-size HDMI connectors and professional 12G-SDI connectors
• Works in all NTSC, PAL, 720p, 1080p, 1080PsF, 1080i and 2160p rates, including 4K DCI in 24/47,95/48
• Powered via USB-C socket (power supply and USB-C cable not included)
• SDI video outputs: Automatically match HDMI video input
• 1 type A HDMI 2.0 video input
• SDI rates: 270 Mbps, 1.5 G, 3 G, 6 G, 12 G
• Multirate support: Automatic detection of SD, HD, 2K, Ultra HD and 4K
• Updates, configurations and power supply: USB Type C
• Reclocking
• Compatible operating systems: Mac Catalina 10.15, Mac Big Sur 11.1 or higher / Windows 10, 64 bit
• Power consumption: Max. 4 W
• Operating voltage range: 4.40 – 5.25 V DC
• Dimensions: 76.5 x 45.8 x 24.8 mm
• Weight: 150 g
• Incl. +5V universal power supply with plug adapters for most countries

Note: No copy-protected HDMI sources can be recorded via the HDMI input. Always check copyright before recording or distributing content.

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since December 2021

• Item number 531444

• Sales Unit 1 piece(s)

• Input HDMI

• Output SDI
