Description

6-Channel Splitter und Booster

• Format: 19″ / 1U
• Professional solution for configuring DMX networks
• Enhances the DMX input signal and distributes it to 6 galvanically isolated outputs
• Is directly connected to the DMX console or DMX devices
• Bright LEDs display on the front panel the DMX and power status of the channels
• The outputs have been positioned on the rearside
• Switchable 120 ohm terminating resistor on the DMX THRU output and the power switch complete the equipment
• For easy access to all ports and for a 180 ° rotated mounting, the rack ears can be mounted on the rear panel
• DMX Inputs: 2 (parallel)
• DMX Input sockets: XLR 3-pin male, XLR 5-pin male
• DMX Thru outputs: 2 (parallel)
• DMX Thru output sockets: XLR 3-pin female, XLR 5-pin female
• DMX Outputs: 6
• DMX Output sockets: XLR 5-pin male, XLR 3-pin male
• Power on/off switch
• DMX Thru terminator
• Display elements: 6 x Power LEDs, 6 x Signal LEDs
• Power supply: IEC power connector
• Operating voltage: 230V AC, 50 Hz
• Power consumption: 15W
• Dimensions (W x H x D): 483 x 44 x 160 mm
• Weight: 2.40 kg
• Includes power cable

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since April 2016

• Item number 385294

• Sales Unit 1 piece(s)

• Type Splitter

• Distribution-type 1in6

• Input 3/5-pole XLR

• 3-pole XLR Outputs Yes

• 5-pole XLR Outputs Yes

• 19″-capable Yes

• RDM-compatible No

• WDMX-capable No
