Description

P10R Alnico Speaker 16ohms has a rich, warm tone. In addition, it accentuates the higher frequencies in sparkling detail.
Thiele-Small Parameters

Voice Coil DC Resistance RE 6.00

Resonance Frequency ƒS 80.0 Hz

Mechanical Q Factor QMS 12.73

Electrical Q Factor QES 2.09

Total Q Factor QTS 1.79

Mechanical Moving Mass MMS 20.3 g

Mechanical Compliance CMS 196 µm/N

Force Factor BxL 5.55 Wb/m

Equivalent Acoustic Volume VAS 66.4 lt.

Maximum Linear Displacement XMAX 1.0 mm

Reference Efficiency nO 1.56 %

Diaphragm Area SD 490.8 cm2

Losses Electrical Resistance RES 39.0?

Voice Coil Inductance @ 1kHz LE 0.50 mH

Constructive Characteristics

Magnet AlNiCo

Voice Coil Winding Copper

Voice Coil Former Kapton

Cone Paper

Surround Integrated Paper

Dust Dome Solid Paper

Basket Pressed Sheet Steel
