Description

The MXR Dookie Drive Pedal captures the tones of those amps in a single pedal so that you can dial in your ownvariations of that famous Dookie sound. MXR borrowed his amps so that the MXR team could carefully analyze all the sonic qualities that make them sound so darn good. After much analysis and A/B testing, MXR engineers rebuilt the amps from scratch in pedal circuit form and fit them into a single housing. The High Gain and Crunch Gain sections each have their own controls, while the Blend control allows you to mix them together just like Green Day did in the studio. If you want some extra scoop in the midrange of the overall output signal, just hit the Scoop switch.

The MXR Dookie Drive Pedal isn’t just for Green Day fans—it’s a totally unique pedal that provides a full harmonic range of overdriven tones for a playing experience that is full of depth and dimension. This special edition features an all-new finish to celebrate the 30th anniversary of Dookie’s monumental release in 1994.

Features:

Blend knob – sets mix of High Gain and Crunch Gain circuits

Output knob – sets overall volume

Gain knob – sets intensity of High Gain circuit’s overdrive

Scoop switch – cuts overall midrange frequencies

Tone knob – controls overall EQ

Footswitch – toggles effect on/bypass (green LED indicates on)

Specifications:

Tone Controls: ±5 dB, 10 kHz

Scoop: -8 dB, 1 kHz

High Gain: +9 dB to +70 dB, 1 kHz

Crunch Gain: +2 dB to +45 dB, 1 kHz

Bypass: True Hardwire

Current Draw: 11 mA

Power: 9V battery (remove bottom plate to install), DC 9 volts (not included)
