With upgraded hardware, the new Loop Core Deluxe allows you to record loop phrases up to 8 hours with unlimited layers in 24-bit high-resolution audio quality into 99 saved memories.

Stop Modes

To finish your playing, you can choose 3 different modes:

1- NORMAL MODE: Double tap – Instant Stop

2- FINISH MODE: Plays until the end of the last measure

3- FADE OUT MODE: 10 seconds Fade-Out Importing and Backing up Your Loop

Next generation looper pedal with a high-definition colour LCD display, stereo inputs/outputs, and optional MIDI control. Loop Core Stereo allows you to create up to 6 hours of music phrases, save them in one of 99 provided memory slots, and play back as stereo loops or even backing tracks. 50 internal drum patterns can also be selected from for rhythm backing. Signal path can be mono, true stereo, split stereo (loop / drum machine) or direct to mixer (with cabinet simulation). A headphones output completes the package for silent loop practice or personal monitoring. A comprehensive looping machine in a standard compact pedal format.

Built-in drum machine with 50 patterns

Up to 6 hours recording time

99 loop storage slots

Built-in cabinet simulator

3.5mm MIDI control input

Full stereo signal path with headphones output

USB-C port for firmware updates

Power supply9Vdc (power adaptor required)

DC input connectionDC5521 jack (for optional adaptor – pin-negative)

Current consumption<120mA

ControlsDrum, Tap, Save, Settings buttons & rotary Value control

InputsL+R 6.3mm mono jack (instrument or line), 3.5mm MIDI jack

OutputsL+R 6.3mm jack outputs, 3.5mm headphones output

RecordingUp to 6 hours

Sampling format44.1kHz, 24-bit

Frequency response20Hz – 20kHz

Memories99

Noise-100dBu

Dynamic range108dB

Dimensions122 x 72 x 48mm

Weight264g
