Description

1.7 voice coil Kapton former and flat aluminium wire
1 horn throat diameter
Titanium diaphgram
Neodymium magnet circuit with copper demodulating ring
106.3 dB sensitivity
Specifications
Nominal Diameter 96mm
Nominal Impedance 8
Rated Power AES (1) (1500 – 20000 Hz) 60W
Continuous Program Power (2) 120W
Sensitivity @ 1W/1m (3) 106.3dB
Voice Coil Diameter 44mm (1.7″)
Voice Coil Winding Depth 2.6mm
Magnetic Gap Depth 3.0mm
Flux Density 2.10T
DC Resistance 5.80
Resonance Frequency 0.8kHz
1.7 voice coil Kapton former and flat aluminium wire
1 horn throat diameter
Titanium diaphgram
Neodymium magnet circuit with copper demodulating ring
106.3 dB sensitivity
Magnet Weight 235g
Net Weight 1.0kg
Recommended Crossover Frequency 1.6kHz
Throat Diameter 25.4mm (1″)
Costructive Characteristics Magnet : Neodymium
Voice Coil Winding Material : Aluminium Flat Wire
Voice Coil Former Material : Kapton
Diaphragm : Titanium
Ferrofluid in Air Gap : No
Spare Part Code : Z009396
