Description

MioMix 202M is a 4-channel mixer with USB player ideal for small home recording, live gigs and podcasting applications that require professional quality level and maximum portability. Two Mic inputs are equipped with noise-less preamps that accepts all main sound sources, such as condenser microphones – thanks to the +48V Phantom Power, dynamic mics, line and high-impedance inputs (guitars, basses, etc.). A stereo line input allow you to connect keyboards, CD players, DJ consoles, tablets, smartphones, etc. The USB & BT player accepts WAV, MP3, WMA and FLAC format audio files, as well as wireless audio streaming (BT). It also records your gig in MP3 format (48kHz/16bit @ 128Kbps). The professional echo digital effect enriches your performance by allowing you to adjust speed and number of repetitions. An indispensable and reliable tool for all small audio applications.

Features
4 Total Channels
2 Mic/Line channels with noiseless preamp, combo connector, Hi-Z input for guitars, +48V Phantom Power, Peak Indicator
1 Stereo Line Channel with ¼” Jack inputs, +4/-10dB Pad Adapter and Peak Indicator
USB Media Player and Recorder (WAV, MP3, WMA, FLAC and BT wireless audio streaming)
2-Band EQ for channels 1 and 2
Digital Echo Effect with Repetition, Delay and Level adjustment
Media Player output level control
Headphone monitor out with level control
XLR Main Outputs with Master Level Control
Stereo 6-Led VU Meter Bar
Rugged and Lightweight Metal Case for Maximum Flexibility and Portability

Specifications
Input Connections Balanced XLR/Jack Combo (Channel 1-2), Balanced ¼” Jack (Channel 3-4)
Output Connection Balanced XLR (Main Out L-R), Stereo ¼” Jack (Phones)
Channel 1-2 Functions +48V Phantom Power, Impedance switch (Line/Hi-Z), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak Led Indicator
Channel 3-4 Functions Impedance switch (+4/-10dB), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak Led Indicator
USB Player Buttons Up/Rewind, Down/Forward, Play/Pause/Enter, Menu
USB Player Functions BT streaming, Music Player, Audio Recording, EQ-Curve Selection
USB Drive Format FAT32 format – max 64GByte
Player File Formats WAV, MP3, WMA, FLAC e streaming audio wireless BT
Recorder File Format MP3 (48kHz/16bit @ 128Kbps)
Effect Functions Echo Repetition Adjustment, Echo Delay Time Adjustment, Echo Level Adjustment
Level Meter 2×6 LED Meter
Max Output Level 3 Vrms
Frequency Response +/-0.5dB, 20Hz-20kHz
Dynamic Range 102dB
THD+N @ 1kHz =0.003%
Stereo Crosstalk 92dB
Power Requirements DC 5V, 0.5A
Power Consumption Max. 2.5W
