Description

The Club XS+ models incorporate all of the great features of the standard Club range, now with the inclusion of a DSP On/Off foot switch socket and an aesthetic overhaul, redesigned control knobs and finished in Studiomaster digital black.

Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions. 3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, and 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jack outputs for auxiliaries and control room, and phono connectors for record and playback.

Ultra compact, lightweight, high quality and extremely versatile, the Club XS is the perfect mixer for any live performance and home recording situation.

Features:

8 inputs

4 mic channels

2 stereo channels

16 DSP effects

Bluetooth

USB/SD media player

Footswitch socket

Specfications:

Mic Gain Range: 6dB to 50dB

Line Gain Range: 10dB to 34dB

EIN: -100dB

Frequency response: 10Hz -20kHz (+1/-3dB)

THD Mic Channel: Under 0.1 percent

Signal to Noise Ratio: 80dB

Output Levels: Max +26dB (Bal), +20dB (unBal)

EQ: Hi 12kHz, Mid 2.5kHz, Lo 45Hz, Lo cut 80Hz

USB/SD: MP3 Audio playback

Record: To USB drive or SD card (128kbps mono)

DSP Effects: 16 DSP effects

Power Requirements: 100V – 240V

Dimension W*H*D: 305 x 80 x 365 (mm)

Weight: 4.5kg
